MASTER B 5 ECA electric heater
MASTER B 5 ECA electric heater
zoom_in
  • MASTER B 5 ECA electric heater
keyboard_arrow_left keyboard_arrow_right

MASTER B 5 ECA electric heater

PLN553.50
Tax included

(450.00 tax excl.)

Efficiency [kW]: 2,5 / 5
Air flow [m3/h]: 510
Rated current [A]: 3 x 7,2
Power [V/Hz]: 400/50
Net weight [kg]: 6,4

Quantity

Nagrzewnica elektryczna B 5 ECA
  • the device was used PTC, which very
  • quickly reaches temperature, thus significantly improving comfort
  • PTC technology makes the device captures the full power immediately after switching
  • PTC heating elements are self-owned power which significantly affects the safe operation of the heater
  • the device has no need for additional external temperature control elements and thermal switches
  • PTC heaters are characterized by compact dimensions, which translates directly into small dimensions and the importance heater
  • PTC heating elements also feature very long life
  • the device is equipped with a comfortable grip
  • You can turn on the heater in full power mode 2 kW or in mid-mode power of 1 kW

Data sheet

Efficiency [kW]
2,5 / 5
Efficiency [Btu/h]
8530 / 17000
Efficiency [Kcal/h]
2150 - 4300
Air flow [m3/h]
510
Rated current [A]
3 x 7,2
Power [V/Hz]
400/50
Switch position 1
OFF
Switch position 2
wentylator
Switch position 3
2,5
Switch position 4
5
Thermostat control
standard
Temperature limited [°C]
5-35
Protection
IPX4
Net weight [kg]
6,4
Gross weight [kg]
7,1
Nagrzewnica elektryczna B 5 ECA
New product

Data sheet

Efficiency [kW]
2,5 / 5
Efficiency [Btu/h]
8530 / 17000
Efficiency [Kcal/h]
2150 - 4300
Air flow [m3/h]
510
Rated current [A]
3 x 7,2
Power [V/Hz]
400/50
Switch position 1
OFF
Switch position 2
wentylator
Switch position 3
2,5
Switch position 4
5
Thermostat control
standard
Temperature limited [°C]
5-35
Protection
IPX4
Net weight [kg]
6,4
Gross weight [kg]
7,1
